High temperature curing epoxy resin liquid for electrical power insulators

Name: High temperature curing epoxy resin liquid for electrical power insulators
Brand: wenyou
Price: 1 USD

Quality High temperature curing epoxy resin liquid for electrical power insulators wholesale

Brand Name : wenyou

Model Number : LW-9425A/B

Certification : ISO9001, ISO14001, SGS, and UL

Place of Origin : China

MOQ : 20kg/pail as sample

Price : Negotiable

Payment Terms : Normally T/T, L/C

Supply Ability : Plenty of raw material in stock

Delivery Time : 7 -10 work days

Packaging Details : 20kg/pail, 220kg/barrel, 1200kg/tank

Classification : Double Components Adhesives

Usage : 66-220kV GIS bowl-type insulators and other insulation components.

Application : Electrical insulators for medium and high voltage applications

Appearance of epoxy resin : Milky white viscous liquid

Viscosity at 25°C : 20000 - 40000mPa.s

Density at 25°C : 1.95 - 2.70g/cm3

Vapor Pressure at 25°C : ≤ 0.01Pa

Flash point : around 135°C

Discription : High temperature curing epoxy resin liquid for electrical power insulators

Contact Now

Brief Introduction

LW-9425A is a modified BPA (bisphenol A) type epoxy resin with aluminum oxide powder.

LW-9425B is a modified carboxylic anhydride hardener with aluminum oxide powder.

High temperature curing epoxy resin liquid for electrical power insulators

Applications

Electrical insulators for medium and high voltage applications, such as 66-220kV GIS bowl-type insulators and other insulation components.

Processing Methods

Conventional gravity casting process under vacuum.

Automatic pressure gelation process (APG).

Production process is adjustable according to client’s present production methods.

Properties

Two-component saturated cyclic epoxy resin system with pre-mixed fillers, slurry liquid at room temperature.

Excellent resistance to thermal shock with superior crack resistance.

Formulation

Epoxy resin	LW-9425A	100 pbw
Hardener	LW-9425B	100 pbw

Advantage

High temperature curing epoxy resin liquid for electrical power insulators

Package Image

High temperature curing epoxy resin liquid for electrical power insulators

Shipment image

Example application image

High temperature curing epoxy resin liquid for electrical power insulators
